Ordering the wrong DTF printhead can turn a routine replacement into an expensive mistake. Two printheads may look similar but still differ in ink compatibility, manifold configuration, nozzle layout and printer support.

This guide compares the Epson XP600, I1600 and I3200 printhead families and explains the differences between the I3200-A1, I3200-U1 and I3200-A1 HD. You’ll also learn how to identify the head installed in your printer and what to check before ordering a DTF printer printhead replacement.

Compatibility note: The printer examples below are reference points, not a substitute for checking your exact machine. Always confirm your printer model, existing printhead part number, ink type and configuration before ordering. You can start by browsing the DTF Gears printheads collection.

Why Printhead Compatibility Matters

A printhead is not a universal component. Your printer is designed around a particular head, ink system, electrical configuration and physical installation.

The most important distinction is often the ink type. Water-based or aqueous Epson heads such as the I1600-A1 and I3200-A1 are different from UV heads such as the I3200-U1. These heads are not interchangeable.

The same applies to different versions within the I3200 family. The I3200-A1 and I3200-A1 HD may look similar, but their manifold configurations are different. The standard A1 supports up to four colours with four manifold inputs, while the A1 HD supports up to eight colours with eight manifold inputs.

Before buying a replacement, verify:

• Your exact printer model

• The existing printhead's part number

• The ink type

• The number of colours supported

• The manifold configuration

• The printer manufacturer's specifications

If you cannot confirm the head yourself, provide your complete printer model to the seller or manufacturer and ask which replacement is specified for that machine.

How to Find Out Which Printhead Your Printer Uses

Finding the correct head usually starts with information already available on your machine or its documentation.

1. Check the printer manual or specification sheet.
   Look for the printhead model or part number. It may identify the head as XP600, I1600-A1, I3200-A1 or I3200-U1.

2. Check the printer settings or software.
   Depending on the machine, the control software may identify information about the printer configuration or installed head. Use this as a reference and compare it with the manufacturer's specifications.

3. Look at the existing printhead.
   If you can safely access the head, check its printed model or part number. For example, the Epson XP600 is identified as F1080-A1.

4. Ask the printer seller or manufacturer.
   Give them the exact printer model rather than simply asking for an "Epson printhead." Different printers can use different heads and configurations.

The key is to match the complete configuration, not just the brand name printed on the component.

Epson XP600 Printhead (F1080-A1)

The Epson XP600, identified as F1080-A1, is a genuine Epson printhead using MicroPiezo technology.

It has 1,080 nozzles arranged in 6 rows and supports variable droplet sizes from 4.5 to 40 pl. Depending on the printer, it can support up to 1440 dpi.

A genuine Epson XP600/F1080-A1 ships with an Epson holographic authenticity sticker.

The Epson XP600 printhead is commonly found in compact 13–14-inch DTF and UV printers. Examples include the Procolored F13 Pro, Epson XP600/XP601, Sublistar DTF-300 Ultra A and Yuxunda DTF-300/400 series.

DTF Gears also carries printer systems built around XP600 configurations. If you're checking your machine before ordering a replacement, see the Procolored DTF printer range.

For a replacement head, see the Epson XP600 printhead F1080-A1.

The XP600 is a common choice for compact machines, but that does not mean it can replace an I1600 or I3200 in another printer. Always match the replacement to the printer's original configuration.

Epson I1600 Printhead

The Epson I1600-A1 is a genuine Epson PrecisionCore MicroTFP printhead designed for water-based or aqueous ink applications.

It has 1,600 nozzles arranged in 4 rows, 600 npi and a 1.33-inch (33.8 mm) print width. It supports up to four colours and is unlocked.

The Epson I1600 printhead is used in select Sublistar and Infiniti printers.

It is also relevant to the xTool Apparel Printer ecosystem. DTF Gears provides information about the xTool DTF printer range, where the Apparel Printer is configured around a genuine Epson I1600-A1 printhead.

If your machine uses this configuration, see the Epson I1600-A1 printhead.

Although the I1600 and I3200 both use PrecisionCore MicroTFP technology, that does not make them interchangeable. The printer's physical configuration and ink system determine which head is appropriate.

Epson I3200 Printhead

The Epson I3200 family contains different versions designed for different ink applications. For replacement purposes, the distinction between the I3200-A1 and I3200-U1 is particularly important.

Epson I3200-A1

The Epson I3200-A1 is a genuine Epson PrecisionCore MicroTFP printhead for water-based or aqueous ink.

It has 3,200 nozzles arranged in 8 rows, 600 npi and a 1.33-inch print width. It supports up to four colours and is supplied with a manifold.

The I3200-A1 is common in higher-productivity 24-inch and wider DTF printers, including Coldesi 24H2/24H4, Sublistar 6004 series, Oric and Fedar models.

DTF Gears' Audley DTF printer range also includes larger DTF systems using Epson I3200-A1 configurations.

For the replacement head, see the Epson I3200-A1 printhead.

If you're operating a larger production machine, you can also browse the Audley DTF printer collection to identify the printer configuration before ordering a replacement.

Epson I3200-U1

The Epson I3200-U1 is the UV version of the I3200 family. It is a genuine Epson, unlocked printhead designed for UV ink only.

It has 3,200 nozzles arranged in 8 rows, 600 npi and a 1.33-inch print width. It is also known as the I3200-S1 HD.

The I3200-U1 is used in UV printers such as the Audley ADL6003UV, Sinocolor and Infiniti UV models.

For this configuration, see the Epson I3200-U1 UV printhead.

UV printer owners should be especially careful when identifying their replacement. DTF Gears also offers the xTool O1 Omni 4-in-1 UV, DTF and DTG printer platform, which has configuration-specific printing systems.

I3200-A1 vs I3200-U1

The main difference is the ink application.

The I3200-A1 is designed for water-based or aqueous ink, while the I3200-U1 is designed for UV ink only. Both have 3,200 nozzles in 8 rows, 600 npi and a 1.33-inch print width, but they are built for different ink systems.

This means a printer designed for an I3200-A1 should not receive an I3200-U1 simply because both are I3200 heads.

If you are asking, can I use a UV printhead in a DTF printer, the answer depends on the printer's original design. A standard water-based DTF printer configured for an I3200-A1 should not be fitted with a U1 as a straightforward replacement.

I3200-A1 vs I3200-A1 HD

The I3200-A1 and I3200-A1 HD are also not interchangeable.

The standard I3200-A1 supports up to four colours and uses four manifold inputs.

The I3200-A1 HD supports up to eight colours and uses eight manifold inputs.

Because the heads can look similar, this is exactly the type of replacement where checking the printer's original specification is important.

XP600 vs I1600 vs I3200 Comparison

This table provides a quick reference when identifying a DTF printhead.

The important takeaway is that nozzle count alone does not determine compatibility.

An I3200 is not automatically a suitable upgrade for an XP600 machine, and an I3200-U1 is not automatically suitable for a water-based DTF printer. Your printer's original head, ink type and physical configuration must match.

Once you've identified your head, shop the DTF Gears printheads collection to review the available replacement options.

Brand-Specific Replacement Printheads

Not every machine should be matched to a generic Epson head by appearance alone. Some printers use brand-specific replacement components or kits designed around a particular configuration.

Procolored K13 Lite

The Procolored K13 Lite has an original printhead replacement specifically intended for the K13 Lite.

If you operate this printer, do not assume that an XP600, I1600 or I3200 is the correct replacement simply because it is an Epson-based head.

See the Procolored K13 Lite original printhead.

xTool O1 Omni

The xTool O1 Omni uses configuration-specific printhead kits, including UV and DTG versions.

That makes it important to select the kit that corresponds to your O1 Omni configuration instead of choosing a replacement based only on appearance.

See the xTool O1 Omni printhead kit.

For operators maintaining an xTool Apparel Printer, DTF Gears also offers an xTool Apparel Printer maintenance kit for routine maintenance needs.

Match the Printhead to Your DTF Printer Configuration

Identifying the printhead correctly is only half the job. You also need to match it to the printer configuration.

For example, DTF Gears' printer lineup covers several different Epson head configurations:

• Compact DTF systems can use XP600/F1080-A1 heads.

• The xTool Apparel Printer uses a genuine Epson I1600-A1 configuration.

• Larger DTF systems such as certain Audley models use Epson I3200-A1 configurations.

• UV systems can use different Epson configurations, including I3200-U1 and configuration-specific UV heads.

This is why searching for "Epson printhead" alone is not enough.

The safest identification process is:

Printer model → existing head → ink type → configuration → replacement head

If all five match, you have a much stronger basis for ordering the correct replacement.

If you are replacing a printhead because you are evaluating a new DTF machine, it can also help to compare the printer's head configuration before buying. DTF Gears' Best DTF Printer Under $2,500 guide compares several printer configurations and identifies the printhead used by each machine. This can help you understand the relationship between the printer model and the replacement parts you may need later.

How to Replace a DTF Printhead Safely

Printhead replacement is a precision service procedure. A new head can be damaged during installation if the electrical connection or cabling is faulty.

Use this checklist:

1. Confirm the replacement head.
   Match the printer model, existing head part number, ink type and configuration before removing the old head.

2. Power down the printer correctly.
   Follow the manufacturer's shutdown and service procedure.

3. Replace the printhead cables.
   Always replace the printhead cables when installing a new head. Old or damaged cables can cause electrical faults that damage the replacement head.

4. Check the ink system.
   Make sure the replacement head is designed for the ink type used by your printer.

5. Install the head carefully.
   Follow the printer-specific installation instructions and protect the nozzle area from contamination or physical damage.

6. Use professional installation when possible.
   Professional installation is recommended, especially if you do not regularly service printheads.

Printheads are consumable service parts and are final sale once installed or exposed to ink. Confirm compatibility before installation.

FAQ

Which printhead does my DTF printer use?

Start with the printer manual or specification sheet and look for the exact printhead model or part number. Then compare that information with the physical head, printer software and manufacturer's replacement information.

What is the difference between XP600 vs I3200?

The XP600/F1080-A1 has 1,080 nozzles in 6 rows, while the I3200 family has 3,200 nozzles in 8 rows. More importantly, they are designed for different printer configurations, so nozzle count alone should not determine a replacement.

Can I use a UV printhead in a DTF printer?

Not automatically. The I3200-U1 is designed for UV ink only, while the I3200-A1 is designed for water-based or aqueous ink. They are not interchangeable.

How do I know if an Epson printhead is compatible with my printer?

Check your exact printer model, existing head part number, ink type and physical configuration. If any of those details are uncertain, confirm the replacement with the printer manufacturer or seller before ordering.

What should I check before ordering a DTF printer printhead replacement?

Confirm the exact head model, ink type, colour configuration and manifold arrangement. Also check whether your printer requires a brand-specific replacement rather than a generic Epson head.

Should I replace the cables when installing a new printhead?

Yes. Replace the printhead cables when installing a new head because old or damaged cables can cause electrical faults that damage the replacement head. Professional installation is recommended.

Choose the Right Printhead Before You Order

The correct replacement starts with identification, not appearance. XP600, I1600 and I3200 heads serve different printer configurations, while the I3200-A1 and I3200-U1 are separated by their ink applications.

Confirm your printer model, existing head and ink configuration before ordering. Then browse the DTF Gears printheads collection to find the appropriate replacement for your machine.

If you're also comparing or maintaining your printer, DTF Gears provides dedicated resources for Audley DTF printers, Procolored DTF printers, xTool DTF printers and the xTool O1 Omni.
